Product Details:
|
| Type: | 6x4 | Horsepower: | 371hp |
|---|---|---|---|
| Fuel Tank: | 400L | Wheel Base: | 3800+1350mm |
| Cab: | HW76 Long Cab, One Bunk | Steering: | ZF8118 Hydraulic Steering With Power Assistance |
| Color: | Any Our Regular Color | ||
| Highlight: | mix concrete truck,cement mixer truck |
||
| Chassis & Add Components | |
| Model | ZZ1257N3641W |
| Engine | |
| Model | WD615.47 |
| Power | 371hp |
| Emission | EURO II |
| Type | 6-cylinder in line, 4-stroke, water-cooled, turbo-charged & inter-cooled, direct injection |
| Kind of Fuel | Diesel |
| Gear Box | HW19710 transmission ,10 forward and 2 reverse |
| Axles | |
| Front Axle Model | HF9 axle. Capacity: 9000kg |
| Rear Axle | HC16 axle. Capacity:2X 16000kg |
| Brake System | |
| Service brake | ABS |
| Parking brake | spring energy, compressed air operating on rear wheels |
| Auxiliary brake | Engine exhaust brake |
| Steering system | |
| Model | ZF8118 |
| Type | hydraulic steering with power assistance |
| Wheels & Tyres | |
| Type | 12.00R20 |
| Cabin |
HW76 long cab, one bunk, air conditioner. |
| Wheelbase | 3800+1350mm |
| Fuel Tank | 400L |
| Concrete mixer capacity | 10m3 |
![]()
![]()
![]()
