White Color Big Horsepower Concrete Mixer Machine 6 x 4 Type Three Axle

White Color Big Horsepower Concrete Mixer Machine 6 x 4 Type Three Axle

SINOTRUK 6*4 371HP Concrete Mixer Truck Cement Mixer Truck Euro II Euro III Euro IV

Description of Mixer Truck:

1). All the bodies adopt integral steel-framed structure, hard and firm, allowing high collision resistance and external force resistance.

2). Automatic painting line consisting of robots ensuring the body appearance quality, corrosion prevention and weather resistance, increasing the effective more than 2 times compared to the conventional electrophoresis painting and allowing higher salvage value of vehicle.

3). Cab manufactured by the welding line composed by international advanced robots, safety and reliable top-level quality in China.

4) Each safety performance index completely meeting the latest legal requirements of China , comprehensively enhancing the safety.

Chassis & Add Components

Model Mixer Truck

ZZ1257N3641W

Engine

Model

WD615.47

Power

371hp

Emission

EURO II

Type

6-cylinder in line, 4-stroke, water-cooled, turbo-charged & inter-cooled, direct injection

Kind of Fuel

Diesel

Gear Box

HW19710 transmission ,10 forward and 2 reverse

Axles

Front Axle Model

HF9 axle. Capacity: 9000kg

Rear Axle

HC16 axle. Capacity:2X 16000kg

Brake System

Service brake

ABS

Parking brake

spring energy, compressed air operating on rear wheels

Auxiliary brake

Engine exhaust brake

Steering system

Model

ZF8118

Type

hydraulic steering with power assistance

Wheels & Tyres

Type

12.00R20

Cabin

HW76 long cab, one bunk, air conditioner.

Cement mixer truck is vehicle that rapidly stirs concrete. The inside is a thin cylinder with two middle and thick ends. There are also some clockwise arranged blades. During the time when the vehicle is transported from the pumping station to the construction site, the effect of preventing cement segregation is caused by the continuous rotation of the fan blades. It consists of a truck chassis, a mixing drum, a transmission system, and a water supply unit. The hydraulic motor, variable displacement piston pump, reducer and cooler are all imported components.
