Euro 2 HW 76 Cab Howo Prime Mover Tractor 4*2 Drive Wheel Truck

Large Image : Euro 2 HW 76 Cab Howo Prime Mover Tractor 4*2 Drive Wheel Truck

Product Details:

Place of Origin:	Shandong
Brand Name:	HOWO Prime Mover Truck
Certification:	CCC
Model Number:	ZZ4187N3241 Prime Mover Truck

Payment & Shipping Terms:

Minimum Order Quantity:	1 unit
Price:	$9,000.00 - $26,500.00
Packaging Details:	in nude
Delivery Time:	5-8 days
Payment Terms:	T/T, L/C
Supply Ability:	100 units per month

Contact Now

Euro 2 HW 76 Cab Howo Prime Mover Tractor 4*2 Drive Wheel Truck

Description

Name:	Prime Mover Truck	Drive Wheel::	4x2
Emission Standard::	Euro 2	Horsepower::	251 - 350hp
Cab::	HW 76	Engine Capacity::	> 8L
Highlight:	tractor trailer truck , tractor head truck

HOWO 4*2 TRACTOR TRUCK

Products Description

Model	ZZ4187N3817E1CB
Engine	Engine model: WD615.47, Euro III emission standard(with oxidation catalytic coverter) Type: 6-cylinder in-line, water cool, dry cylinder , turbo charged inter cooling, electric control, regulated press gas control, spark plug ignition and lean-burn; Maximum output: 340PS (250kW) at 2200 rpm Maximum torque: 1160Nm at 1200-1600rpm Bore(mm)Stroke(mm): 126130; Displacement: 9.726L Compression ratio: 11:1 Lowest fuel consumption: ≤189g/kWh Max. exhaust temperature: ﹤ 580 ℃ Thermostat with 80℃ opening bengin; Rigid fan; Option:Thermostat with 71℃ opening begin: Visco fan;
Clutch	Single-plate dry coil-spring cluth, diameter 420mm or SINOTRUK’s 430C diaphragm spring clutch, hydraulically operating with air assistance;
Transmission	Transmission, model HW15710, 10 forward and 2 reverse Ratio:14.28; 10.62; 7.87; 5.88; 4.38; 3.27; 2.43; 1.80; 1.34; 1.00; 13.91/3.18(R) Transmission, model HW19710T, 10 forward and 2 reverse Ratio:14.36; 10.66; 7.875; 5.82; 4.38; 3.28; 2.74; 1.80; 1.33; 1.00; 14.01/3.20(R)
Propeller Shaft	Double universal joint propeller shaft with gear-shaped coupling flange
Front Axle	New HF7 series, with drum brake system Steering with double T-cross section beam
Rear Axle	Pressed axle housing, central single reduction with planetary wheel reduction and differential locks between wheels and axles, Ratio: 4.80, 4.3 Option: Single-reduction, Axle shaft pressed welded housing, Ratio: 4.875 (HW1279 or MCY13(Q))
Chassis	Frame: High-strength U-profile frame, all cold riveted cross members and reinforced sub frame; Front suspension:9 semi-elliptic leaf springs with hydraulic telescopic double-action shock absorbers and stabilizer; Rear suspension: 12 semi-elliptic leaf springs with bogie spring; CNG Cylinder: CNG cylinder : 8x140L; Option: 4x80L+8*140L Fifth Wheel size: 2 inch; Option: 3.5 inch fifth wheel;
Steering	ZF8098, hydraulic steering with power assistance (RHD or LHD) Ratio: 22.2-26.2:1
Braking System	Front and rear drum brake, four-circuit protection valve Service brake: dual circuit compressed air brake Parking Brake: spring energy, compressed air operating on rear wheels Auxiliary brake: engine exhaust brake Option: ABS
Wheel & Types	Rims: 8.5-20,10 hole-steel or 8.25x22.5; Types: 295/80R22.5, 11R22.5-16PR, 315/80R22.5; 11.00-20; 11.00R20; 12.00-20; 12.00R20
Driver’s cab	Long cab, all steel forward control, 55°hydraulic tilting to the front, 2-arm windscreen wiper system with 3 speeds, VDO electrical control system, laminate windscreen, with casted-in radio aerial, adjustable driver’s seat and rigid adjustable co-driver’s seat, heating & ventilation system, with stereo radio/cassette recorder, sun visor, single bunk, with 4-point support full floating suspension+ shock absorbers with transverse stablilizer. belt, air conditioner, adjustable steering wheel.
Electrical System	Operating voltage:24V, negative grounded; Starter: 24V, 7.5KW Alternator: 3-phrase, 28V, 1540W Batteries: 2×12V, 165Ah Cigar-lighter, horn, headlamp, fog light, brake lights, indicators and reverse lamp
Dimensions in mm	Wheel base (mm) Front wheel track (mm) Rear wheel track (mm) Front overhang (mm) Rear overhang (mm) Approach angle(°) Departure angle(°) Overall Dimension (mm)	3825+1350 2022/2041 1830 1500 725 16 70 7400×2496×3700
Weight in kg	Dead weight (kg) Rated loading capacity at fifth wheel (kg) Gross combination weight (kg) Front axle loading capacity (kg) Rear axle loading capacity (kg)	11000 14890 45000 7000 21000
Performance	Maximum driving speed(km/h) Maximum gradeability (%) Minimum ground clearance(mm) Minimum turning radius (m) Fuel consumption(L/100km)	90(reference data) 35 298 17.1 35(reference data)
