                        Product Details:


 |
| Drive Wheel: | 6x4 | Capacity (Load): | 20-35ton |
|---|---|---|---|
| Horsepower: | 336hp | Emission Standard: | Euro2 |
| Condition: | New | Transmission Type: | Manual |
| Front Axles: | 9TON | Rear Axles: | 16TON |
| Max Speed: | 90km/h | Tires: | 12.000R20 Steel ,10+1 Spare |
| Highlight: | Hydraulic Mobile Truck Mounted Crane,12Ton Truck Mounted Crane,8 Ton telescopic truck mounted crane | ||
A boom arm crane truck is a type of vehicle equipped with a crane that extends to lift and move heavy materials. It combines a truck chassis with a hydraulic crane mounted on it. Here’s a quick breakdown of its key features and uses:
Boom Arm: The crane's boom arm can extend and retract, and it’s often articulated, allowing it to reach over obstacles and position loads precisely.
Hydraulic System: Most boom arm cranes use hydraulic systems to provide the lifting power and allow for smooth operation.
Versatility: These trucks are commonly used in construction, logistics, and utilities for tasks like lifting building materials, moving machinery, or positioning heavy equipment.
Mobility: Since the crane is mounted on a truck, it’s easy to transport the equipment to different job sites, making it more flexible compared to stationary cranes.
Controls: Operators can control the crane using levers or joysticks, often from a cabin located on the truck.

| Driving Type: | 6X4 |
| Cab: | HW76,1 bunk,with air condition |
| Gear Box: | HW19710 10 Forward and 2 Rearward |
| Front Alex: | VGD95 Drum |
| Rear Axle: | MCX16 |
| Tyre: | 12.00R20 |
| ABS: | No |
| Colour: | optional |
| Fuel tank: | 400L |
| Engine: | WP10.300E22, 300HP, EUROII |
| Truck-mounted Crane model: | SQ8SK3Q |
| Max lifting capacity: | 8000kg |
| Max. working range: | 11.5m |
| cargo body: | 5000×2300×600mm (bottom 3mm side 1.5 mm) |






Our company will offer you the high quality proudcts with a low price, Quick delivery,and professional after-sale service.
According to clients' requirements, we can customize different loading capacity and volume.
Product Description:
1. Competitive price
2. Strong body
3. Quick parts
4. Truck sale from factory
What we can do for customers:
1. The satisfied product with high level standard;
2. The full aspect service from order to shipping;
3. Give customer most suitable advice when customer has special needs for your transportation or construction;
4. Help customer to get the related spare parts of trailer or tractors if customer needs.




Q. What is your payment terms ?
A: 30% TT before produce and 70% TT before shipment . or 100% LC at sight ( irrevocable ).
Q. How long time you could delivery goods to customer ?
A : Generally 25 days of working , after we receive your deposits .
Q: How you can ensure you have deliveried goods to customers ?
A: We will give you the complete shipping information details for you to confirm.
Q. How you could supply customers after sales services ?
A: We will reply you at first time and help you resolve the problems within 24 hours . If it really need us to your local , we will send your professional person to your local to help you resolve problems without any hesitation , supply you all-around after-sales services including machine maintenance and operation and technical training services etc .
