Sinotruk Howo 6x4 371hp Dump Trucks with Crane 10 Ton Singapore Truck Mounted Telescopic Boom Crane

Sinotruk Howo 6x4 371hp Dump Trucks with Crane 10 Ton Singapore Truck Mounted Telescopic Boom Crane
Sinotruk Howo 6x4 371hp Dump Trucks with Crane 10 Ton Singapore Truck Mounted Telescopic Boom Crane Sinotruk Howo 6x4 371hp Dump Trucks with Crane 10 Ton Singapore Truck Mounted Telescopic Boom Crane Sinotruk Howo 6x4 371hp Dump Trucks with Crane 10 Ton Singapore Truck Mounted Telescopic Boom Crane Sinotruk Howo 6x4 371hp Dump Trucks with Crane 10 Ton Singapore Truck Mounted Telescopic Boom Crane Sinotruk Howo 6x4 371hp Dump Trucks with Crane 10 Ton Singapore Truck Mounted Telescopic Boom Crane Sinotruk Howo 6x4 371hp Dump Trucks with Crane 10 Ton Singapore Truck Mounted Telescopic Boom Crane

Large Image :  Sinotruk Howo 6x4 371hp Dump Trucks with Crane 10 Ton Singapore Truck Mounted Telescopic Boom Crane

Product Details:
Place of Origin: Jinan
Brand Name: HOWO
Certification: CE, ISO9001, CCC
Model Number: jnhtc
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: USD32000-48000
Packaging Details: in nude, polish with wax
Delivery Time: 20days
Payment Terms: L/C, T/T
Supply Ability: 1000 units per month

Sinotruk Howo 6x4 371hp Dump Trucks with Crane 10 Ton Singapore Truck Mounted Telescopic Boom Crane

Description
Max Lifting Moment: 10 T Max Lifting Capacity: 5000kg
Truck Chassis: 6x4 Rotation Angle: (360°)All Rotation
Crane Weight: 2117kg Installation Space: 1050mm
Crane Type: Straight Arm Crane
Highlight:

Sinotruk Howo 6x4 dump truck with crane

,

10 ton truck mounted telescopic boom crane

,

371hp dump truck with crane

Sinotruk Howo 6x4 371hp Dump Trucks with Crane 10 Ton Singapore Truck Mounted Telescopic Boom Crane




















Sinotruk Howo 6x4 371hp Dump Trucks with Crane 10 Ton Singapore Truck Mounted Telescopic Boom Crane 0







Detailed Photos

Chassis
Chassis Type
SINOTRUK HOWO 6X4 DUMP TRUCK WITH CRANE
Chassis model
ZZ1317V3267B1
Wheelbase (mm)
3200mm
Engine
Model
WP12.400E201, Euro II (optional)

Type
Diesel

Horsepower
371HP

Option
From 336HP to 420HP for option
Gear box

HW19710,10 forward & 2 reverse
Cab
Type
HW76 cab(optional)
Braking system
Drive brake
Hydraulic drum

Parking brake
Cutting-off air brake
Tire
12.00R20 radial tire with one spare
Front axle
VG95 (drum)
Rear axle
MCP16ZG(twin axle, drum, Ratio 5.26)
Fuel tank (L)
400L
Cargo box
Carriage dimension
7500*2300*600mm(optional)
Thickness
Bottom 3mm, side 1.5mm(optional)
Crane
Capacity
12 tons(optional)
Type
Straight arm/Knuckle
Lifting height
12.5m(optional)
Delivery time
About 30 days after prepayment

Crane truck


Crane truck, also known as truck mounted lifting and transportation vehicle, is a device that uses hydraulic lifting and telescopic systems to lift, rotate, and lift goods. It is usually installed on cargo trucks. It generally consists of a truck chassis, cargo compartment, power take-off, and crane. According to the type of crane, it is divided into straight arm type and folding arm type. According to tonnage, it is divided into 2 tons, 3.2 tons, 5 tons, 6.3 tons, 8 tons, 10 tons, 12 tons, 16 tons, and 20 tons.

Precautions during the operation of the on-board crane:
1) Understand the size of the lifted cargo, find the distance from the center of the cargo to the center of the crane column, and check the lifting capacity parameters of the crane based on the distance. 2) The lifting capacity (torque) of the crane is fixed, and the larger the working radius of the crane. The lighter the lifted cargo, the smaller the working radius, and the heavier the lifted cargo. (The working radius refers to the horizontal distance from the center of the torque to the hook.)- 3) Considering the lifting capacity of the crane and the load-bearing capacity of the chassis, the larger the beam, the better. If the crane is larger and the chassis is smaller, it will cause deformation and fracture of the beam. A smaller chassis reduces the power of the engine, which affects the lifting capacity of the crane. So when considering a 230mm beam, we choose a crane weighing less than 3 tons. When considering a 250mm beam, consider a crane weighing less than 6 tons. A 280mm beam can be equipped with a crane weighing less than 8 tons. A crane weighing less than 10 tons can be considered for chassis with rear eight wheels and front four wheels.


Sinotruk Howo 6x4 371hp Dump Trucks with Crane 10 Ton Singapore Truck Mounted Telescopic Boom Crane 1Sinotruk Howo 6x4 371hp Dump Trucks with Crane 10 Ton Singapore Truck Mounted Telescopic Boom Crane 2Sinotruk Howo 6x4 371hp Dump Trucks with Crane 10 Ton Singapore Truck Mounted Telescopic Boom Crane 3Sinotruk Howo 6x4 371hp Dump Trucks with Crane 10 Ton Singapore Truck Mounted Telescopic Boom Crane 4Sinotruk Howo 6x4 371hp Dump Trucks with Crane 10 Ton Singapore Truck Mounted Telescopic Boom Crane 5

In the engineering construction, truck crane plays an important role. It assists workers to complete tasks such as lifting, loading and unloading, greatly improving work efficiency and reducing labor consumption. At the same time, the safety performance of the crane is also concerned, and the advanced safety device ensures the stability and safety of the lifting process.
Truck crane, with its unique advantages and excellent performance, has become an indispensable tool in engineering construction. It has witnessed the successful implementation of numerous engineering projects, contributing to the development and construction of the city.





Packaging & Shipping





Sinotruk Howo 6x4 371hp Dump Trucks with Crane 10 Ton Singapore Truck Mounted Telescopic Boom Crane 6

Sinotruk Howo 6x4 371hp Dump Trucks with Crane 10 Ton Singapore Truck Mounted Telescopic Boom Crane 7

Sinotruk Howo 6x4 371hp Dump Trucks with Crane 10 Ton Singapore Truck Mounted Telescopic Boom Crane 8







Company Profile

Sinotruk Howo 6x4 371hp Dump Trucks with Crane 10 Ton Singapore Truck Mounted Telescopic Boom Crane 9







FAQ

Q. What is your payment terms ?
A: 30% TT before produce and 70% TT before shipment . or 100% LC at sight ( irrevocable ).
Q. How long time you could delivery goods to customer ?
A : Generally 25 days of working , after we receive your deposits .
Q:How you can ensure you have deliveried goods to customers ?

A: We will give you the complete shipping information details for you to confirm.
Q. How you could supply customers after sales services ?
A: We will reply you at first time and help you resolve the problems within 24 hours . If it really need us to your local , we will send your professional person to your local to help you resolve problems without any hesitation , supply you all-around after-sales services including machine maintenance and operation and technical training services etc .
