Product Details:
|
| Material: | Q345 | Axle: | FUWA, BPW |
|---|---|---|---|
| Tire: | 12.00R20, 315/80.22.5 | Support Leg: | 28T |
| Kingpin: | 2’’ Or 3,5’’ | Name: | 3 Axles Van |
| Axle And Suspension: | 13T Load Capacity, 150 X 150 Square Axle. | Accessories: | 2pcs Spare Wheel Carries |
| Highlight: | container semi trailer,tank semi trailer |
||
3 Axles Van Type Box Semi-trailer Lightweight design with Q700 steel "I" beam.
Specification:
| Name | 3 Axles Van Type Box Semi-trailer |
| Chassis | Star Trailer chassis made of Q345 steel. Strengthened “I” section main beams are welded automatically by submerged welding machine. |
| Kingpin | 2’’ or 3,5’’ king pin detachable from below made by SAE standards bolted type |
| Brake system |
Double circuit brake system. The rear axle with T30/30 spring brake chamber and the first 2 axles with T30 service brake chamber. WABCO, SEALCO or equivalent brand.
|
| Enhanced Features Options |
- Lightweight design with Q700 steel "I" beam. - Other dimensions available.
|
| Electric system | 24 Volt lighting installation with 7 pin plug socket. Philip or equivalent brand. |
| Landing gear |
Single side operation, 2 speeds, telescopic type. JOST, Holland or equivalent brand.
|
| Tyres |
12 R22.5 or 385/65 R22.5 or 315/80 R22.5. Triangle, Bridgestone, Goodyear, Continental.
|
| Axle and suspension |
13T load capacity, 150 x 150 square axle. BPW, FUWA, JMCG. Mechanical suspension or air suspension
|
| Accessories |
2pcs Spare wheel carries 1 pc tool box Reflector
|
| ABS Optional | |
Advantages:
Van trailers is available with curtain Side, Open Top Van, Wing Type Van, Reefer Van per custormer operational requirement. It is widely used for valuable goods such as electronic product,Wine, tobacoo and items which need to be well protected.
