Product Details:
|
| Size: | 12000*2500*3600mm | Painting And Logo:: | Can Customize According To Your Requirment |
|---|---|---|---|
| Inside Dimension:: | 11850*2350*2000mm | Cover: | With Top Cover |
| Axle Number: | 3 | Axle Weight Load: | 13T |
| Color: | Optional | Max Payload: | 40T |
| Highlight: | van semi trailer,tank semi trailer |
||
40ton Max Payload 3 axles 40 ton payload Steel semi van box trailer ,
Quick Details of Heavy Duty Semi Trailers
| Use: | Truck Trailer | Type: | Semi-Trailer,semi trailer | Material: | Steel |
| Certification: | CCC BV WMI ISO9001 | Size: | 12000*2500*3600mm | OEM No.: | utility cargo box trailer |
| Max Payload: | 40ton | Place of Origin: | Shandong China (Mainland) | Brand Name: | C |
| Model Number: | utility cargo box trailer | color: | as client's requriment | tire: | to be choosed by customer |
| painting and logo: | can customize according to your requirment | landing gear: | JOST or FUWA | trailer loading capacity: | can customize according to your requirment |
| Inside dimension: | 11850*2350*2000mm | ||||
| Packaging Detail: | naked utility cargo box trailer |
| Delivery Detail: | 15days utility cargo box trailer |
3 axles van semi trailers,utility cargo box trailer
| Specification | |
| Dimensions(L*W*H) | 12000*2500*3600mm |
| Inside Dimensions | 11850*2350*2000mm |
| Board thick | 1.5mm |
| Platform plate | 3mm (metal deck) |
| Main Beam |
The height of the beam is 500 mm, upper plate is14mm, down plate is 16mm,middle plate is 8mm. |
| Side beam | 14 # steel channel |
| Cross beam | 10# steel channel |
| Loading capacity | 40000kg |
| Top cover | With top cover |
| Double Doors | 7 |
| Axle number | 3 |
| Axle weight load | 13T |
| Axle brand | FUWA Brand |
| King pin | 3.5"(90#) |
| Support legs | 28Ton standard |
| Suspension | Mechanical Suspension |
| Steel spring number | 10/10/10 |
| Steel spring thickness | 1.3mm |
| Tire | 12R22.5 12pcs |
| Wheel base | 6880+1310+1310 |
| Spare tire carriers | 2 piece |
| Brake system | Dual Line braking system |
| Brake Air Chamber | Two double and two single chamber |
| Tools box | 2 |
| Voltage | 24V |
| Receptacle | 7 ways (7 wire harness) |
| Side marker lamp | LED type |
| Shipping terms | Naked |
| painting | According to customer’s requirement |
