Product Details:
|
| Use: | Truck Trailer | Max Payload: | 60t |
|---|---|---|---|
| Material: | Steel | Type: | 6*4 |
| Suspension: | Air Suspension | Axle: | 3 Axles |
| Color: | Customers Optional | King Pin: | 2"(50mm)or3.5"(90mm) JOST |
| Condition: | New | Tire Size: | 11.00r20 /12r22.5/8.25r20 |
| Highlight: | 11.00r20 3 Axle Semi Trailers,11.00r20 Low Bed Semi Trailers |
||
Chinese Very Good Quality hydraulic modular trailer
| Weight: | ||
| loading capacity | 60T | |
| Axle weight load | 13T | |
| Specification: | ||
| Axle number | 2-4 | |
| Axle brand | optional | |
| Suspension | Common mechanical | |
| king pin | 2'or 3.5' traction pin | |
| Dimension(L*W*H) | 13000*300*1650 | |
| Support legs | 28T | |
| Wheel rim | 8.5-20,9.0-20,8.25-22.5,9.0-22.5 steel wheel rim optional upon choice | |
| Wheel base | 6680+1310+1310 | |
| Steel Spring | 10/10/10 pieces per axle | |
| Ladder | Mechanical ladder Or Air Ladder | |
| Landing gear | Manual operating, Heavy duty landing gear (Brand Optional upon chioce) | |
| Floor | 3-5 Diamond plate | |
| Tool box | 1 set | |
| Light | Tail lamp with turn signal, brake light & reflector, side lamp etc. | |
| Painting | 1coat of anticorrosive prime, twice coats of final paint | |
| Tire: | ||
| Tire spec. | 12R22.5 Vacuum tire /11.00R20 | |
| Number of tire | 8 or 12 or 16 pieces | |
| Spare tire | 2 pieces | |
| Frame: | ||
| Main beam |
The height of the beam is 500-550mm; Upper plate:16-22mm;Down plate is 18-25mm;Middle plate is 10-16mm.
|
|
| Side beam | 20-25 channel or H steel | |
| Brake: | ||
| Brake brand | Optional upon choice | |
| Brake chamber | Six big chamber( Brand Optional upon choice ) | |
| Brake system | Dual Line Brake system (ABS Optional upon choice) |
1) One year quality assurance for three key parts: axles, engine, transmission.
2) Other spare part could be supplied by OEM at coast prices.
3) Regularly callback to know the vehicle's working status.
4) The overseas engineers are always ready to deal with unexpected needs.
5) All trucks and trailers are new and be customized to meet all your requirement.
6) All trucks and trailers are with 12 months quality guarantee.
7) CKD and SKD are available.
8) Technical support are provided
