Hot HOWO TX Dump Truck 6x4 10 Wheel Howo 380HP Tipper Truck Price High Quality

Hot HOWO TX Dump Truck  6x4 10 Wheel Howo 380HP Tipper Truck Price High Quality
Hot HOWO TX Dump Truck  6x4 10 Wheel Howo 380HP Tipper Truck Price High Quality Hot HOWO TX Dump Truck  6x4 10 Wheel Howo 380HP Tipper Truck Price High Quality Hot HOWO TX Dump Truck  6x4 10 Wheel Howo 380HP Tipper Truck Price High Quality Hot HOWO TX Dump Truck  6x4 10 Wheel Howo 380HP Tipper Truck Price High Quality Hot HOWO TX Dump Truck  6x4 10 Wheel Howo 380HP Tipper Truck Price High Quality Hot HOWO TX Dump Truck  6x4 10 Wheel Howo 380HP Tipper Truck Price High Quality

Large Image :  Hot HOWO TX Dump Truck 6x4 10 Wheel Howo 380HP Tipper Truck Price High Quality

Product Details:
Place of Origin: China
Brand Name: Howo
Certification: ISO CCC
Model Number: jnhtc
Payment & Shipping Terms:
Minimum Order Quantity: 1 UNIT
Price: USD23100-25410
Packaging Details: nude
Delivery Time: 45 Work days
Payment Terms: L/C, T/T
Supply Ability: 50 units per week

Hot HOWO TX Dump Truck 6x4 10 Wheel Howo 380HP Tipper Truck Price High Quality

Description
Horsepower: 420hp Colorwhite: White
Fuel Tank: 400L Drive Wheel: 6x4
Tyres: 12.00R20 Capacity (Load): 21 - 30T
Highlight:

10wheel HOWO TX Dump Truck

,

380HP HOWO TX Dump Truck

,

6x4 HOWO TX Dump Truck

Hot HOWO TX Dump Truck 6x4 10wheel Howo 380HP Tipper Truck Price High-Quality



Model
ZZ3257V3847B1
Driver's Cab
HW76 extended cab, with one sleeper berth ,with air conditioner, air seat for driver. MP3
Engine
Model: WP12.400E201, Euro II emission standard, 4 stroke injection diesel engine, 6
cylinder in-line with water cooling, turbo-charging & inter cooling.
Maximum output: 400PS (294kW) at 2100 rpm
Maximum torque: 2060Nm at 1200-1500rpm
Bore: 126mm Stroke: 155mm
Displacement: 11.596L
Brand: Weichai
Steering
Model: BOSCH
Hydraulic steering with power assistance
Left hand driving
Clutch
Φ430 Pull-type diaphragm spring clutch
Transmission
Model: HW19710, 10 forward and 2 reverse
Manual type
With transmission power take-off HW70
Max Torque: 1900N·M
Front Axle
Model: HF9
Drum brake system
Rated loading capacity :9000kgs
Rear Axle
Model: MCP16ZG
Capacity: 16000kgs
Drum braking steering axle,self-adjusting arm
Speed ratio:
Wheelbase
3800+1350 mm
Brake System
Type :Wabco braking system
ABS 4S/4M
Engine exhaust valve brake
Oil Tanker
300L aluminum alloy fuel tank
Tires
Types: 12.00R20 radial tire; 18PR
10 pcs, plus one pc spare tire
Bumper
Metal bumper
Dump body
5600*2300*1500mm, 8mm for bottom and 6 mm for side plate, rectangular box, Chinese brand front lifting cylinder, with integral
fender, headlight cover.
Dimensions in mm
Front wheel track (mm): 2022
Rear wheel track (mm):1830
Overhang(front/rear) (mm):1500/1870
Overall Dimension (mm): 8650*2580*3450
Weight in kg
Dead weight (kg):13500
Gross vehicle weight (kg):25000




A dump truck is a powerful and versatile vehicle designed for transporting and unloading bulk materials. Here's an in-depth look at dump trucks:

Types of Dump Trucks

  1. Standard Dump Truck:

    • Configuration: Truck chassis with a mounted dump body.
    • Operation: The bed is lifted using a hydraulic ram, dumping materials at the rear.
  2. Articulated Dump Truck (ADT):

    • Configuration: Consists of two parts: a tractor and a trailer, joined by a pivot point.
    • Operation: Offers better maneuverability on rough terrain due to its articulation.
  3. Transfer Dump Truck:

    • Configuration: A standard dump truck pulling a separate trailer with an additional dump bed.
    • Operation: Allows for greater load capacity by using an additional dump trailer.
  4. Side Dump Truck:

    • Configuration: Dump body capable of tilting to the side.
    • Operation: Efficient for quickly unloading materials to the left or right side.
  5. Super Dump Truck:

    • Configuration: Enhanced standard dump truck with additional axles.
    • Operation: Increases payload capacity and distributes weight more effectively.
  6. Dump Trailer:

    • Configuration: A trailer equipped with a hydraulic lift, towed by another vehicle.
    • Operation: Used for transporting bulk materials with the convenience of detaching the trailer.

Key Features

  • Capacity: Measured in cubic yards or tons, indicating how much material can be carried.
  • Hydraulic System: Powers the lifting mechanism for unloading materials.
  • Chassis: The structural frame supporting the dump body.
  • Axles and Tires: Designed to support heavy loads and provide stability.



Hot HOWO TX Dump Truck  6x4 10 Wheel Howo 380HP Tipper Truck Price High Quality 0Hot HOWO TX Dump Truck  6x4 10 Wheel Howo 380HP Tipper Truck Price High Quality 1Hot HOWO TX Dump Truck  6x4 10 Wheel Howo 380HP Tipper Truck Price High Quality 2Hot HOWO TX Dump Truck  6x4 10 Wheel Howo 380HP Tipper Truck Price High Quality 3Hot HOWO TX Dump Truck  6x4 10 Wheel Howo 380HP Tipper Truck Price High Quality 4





Hot HOWO TX Dump Truck  6x4 10 Wheel Howo 380HP Tipper Truck Price High Quality 5Hot HOWO TX Dump Truck  6x4 10 Wheel Howo 380HP Tipper Truck Price High Quality 6Hot HOWO TX Dump Truck  6x4 10 Wheel Howo 380HP Tipper Truck Price High Quality 7Hot HOWO TX Dump Truck  6x4 10 Wheel Howo 380HP Tipper Truck Price High Quality 8Hot HOWO TX Dump Truck  6x4 10 Wheel Howo 380HP Tipper Truck Price High Quality 9
