Product Details:
|
| Brand: | HOWO Heavy Duty Dump Truck | Color: | White Red Yellow |
|---|---|---|---|
| Drive Wheel: | 8*4 | Capacity (Load): | 32-50 Tons |
| Fuel Type: | Diesel | Lift Type: | Front Lift System |
| Highlight: | heavy dump truck,sinotruk howo dump truck |
||
| Truck Model : | ZZ3317N4267A |
| Truck Brand : | SINOTRUK – HOWO |
| Driving Style : | Left Hand Driving |
| Dimension (L*W*H)(unloaded)(mm) : | 10825×2496×3590 |
| Cargo body size (L*W*H, mm) : | 7800×2300×1500 |
| Cargo thickness (mm): | Bottom: 8 |
| Side: 6 | |
| Lift type of Carriage : | Front lifting |
| Approaching angle / Departure angle (°) : | 19/22 |
| Overhang(front / rear)(mm) : | 1500/1975 |
| Wheel base (mm): | 1800+4200+1350 |
| Max speed (km/h) : | 75 |
| Curb weight (kg) : | 15480 |
| Loading Weight (kg) : | 31000 |
| Fuel tanker capacity (L) : | 300 |
| Fuel consumption (L/km) : | 28L/100 |
| Clutch : | Single-plate dry clutch Φ 430mm |
| Fuel type : | Diesel |
| Horse Power, max (kw/rpm) : | 371HP |
| Emission : | EURO II |
| Transmission : | HW19710 , 10 forwards and 2 reverse |
| Brake system : | Dual circuit compressed air brake |
| Parking brake : |
spring energy, compressed air operating on rear wheels |
| Auxiliary brake : | Engine exhaust brake |
| Steering system : | ZF8118 hydraulic steering with power assistance |
| Front axle : | HF9 , Steering with double T-cross section beam |
| Rear axle : |
HC16,Pressed axle housing,central double reduction with differential locks between axles and wheels |
| Color : | Optional( White , Red , yellow or as your needs ) |
| Tyre : | 12.00R20 |
| Cab : |
HOWO76 cab,single sleeper with air conditioner all-steel forward control,55º hydraulically tiltable to the front,2-arm windscreen wiper system with three speeds,laminated windscreen with casted-inradio aerial,hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat,with heating and ventilating system,outer sun visor,adjustable roof flap,with stereo radio/cassette recorder safety belts and adjustable steering wheel,air horn,with 4-point support fully floating suspension and shock absorbers |
