Togo Sinotruck HOWO 6x4 Mining Dump Truck 20 Cubic Meter 10 Wheel 420hp Tipper Truck

Togo Sinotruck HOWO 6x4 Mining Dump Truck 20 Cubic Meter 10 Wheel 420hp Tipper Truck
Togo Sinotruck HOWO 6x4 Mining Dump Truck 20 Cubic Meter 10 Wheel 420hp Tipper Truck
Togo Sinotruck HOWO 6x4 Mining Dump Truck 20 Cubic Meter 10 Wheel 420hp Tipper Truck Togo Sinotruck HOWO 6x4 Mining Dump Truck 20 Cubic Meter 10 Wheel 420hp Tipper Truck Togo Sinotruck HOWO 6x4 Mining Dump Truck 20 Cubic Meter 10 Wheel 420hp Tipper Truck Togo Sinotruck HOWO 6x4 Mining Dump Truck 20 Cubic Meter 10 Wheel 420hp Tipper Truck Togo Sinotruck HOWO 6x4 Mining Dump Truck 20 Cubic Meter 10 Wheel 420hp Tipper Truck

Large Image :  Togo Sinotruck HOWO 6x4 Mining Dump Truck 20 Cubic Meter 10 Wheel 420hp Tipper Truck

Product Details:
Place of Origin: JINAN, CHINA
Brand Name: SINOTRUK
Certification: CCC
Model Number: ZZ3257N3847C1
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: USD41000 for one unit
Packaging Details: nude packing
Delivery Time: 5 working days
Supply Ability: 1000 sets for one month
Contact Now

Togo Sinotruck HOWO 6x4 Mining Dump Truck 20 Cubic Meter 10 Wheel 420hp Tipper Truck

Description
Color: Red, White, Blue, Green, Yellow Engine: WD615.47
Cabin: HW76, HW70 Axle: HC16
Engine Capacity: > 8L Fuel Type: Diesel
Condition: New Gross Vehicle Weight: 25000
Transmission Type: Manual Horsepower: 351 - 450hp
Emission Standard: Euro 2,Euro 3
Highlight:

HOWO 6x4 Mining Dump Truck

,

Sinotruck 420hp Mining Dump Truck

,

Togo Sinotruck 420hp Tipper Truck

Truck Dump Togo Sinotruck HOWO 6x4 20 Cubic Meter 10 Wheel 420hpTipper Truck Mining Dump Truck


Model
ZZ3257N3647B
Cabin
HW76, with two seats and one bed, 2-arm windscreen wiper system with three speeds, damped adjustable driver's seat, with heating
and ventilating system, exterior sun visor, safety belts, adjustable steering wheel, air horn, air conditioner, with transverse
stabilizer, with 4-point support fully floating suspension + shock absorber + air roof spoiler

Engine
Model
WD615.47

Horse Power (Hp/rpm)
371/2200

Max.Toruqe(Nm/rpm)
1820/1100-1500

Displacement (L)
9.726

Type
DIESEL, EURO II emission, 6-cylinder in-line with water cooling, turbo-charging and intercooling, 4-stroke common rail electronic
controlled diesel engine
Clutch
Φ430 Diaphragm spring clutch, hydraulic operating with air assistance
Transmission
HW19712, 12 speeds forward and 2 speeds reverse.
Front Axle
HF9, Steering with double T-cross section beam, Rated loading capacity: 9,000kgs.
Driving Axle
HC16, Pressed axle housing, central reduction with hub reduction and with differential locks between wheels and axles(Ratio: 4.42,
4.8)
Suspension
Front suspension: hydraulic telescopic double-action shock absorbers and stabilizer; Rear suspension: leaf semi-elliptic springs,
bogie spring and stabilizer
Steering System
ZF power steering, model ZF8118, hydraulic steering with power assistance
Brake System
Service brake: Dual circuit compressed air brake; Parking brake (emergency brake): Spring energy, compressed air operating;
Auxiliary brake: Engine exhaust brake
Electrics
Single wire, 24 V, negative grounded; Alternator: 1540W; Start Motor:7.5kW;Battery:2*12V/165Ah
Tire
12.00R20
Fuel Tank(Gas Tank) Capacity (L)
300L Diesel Tank
Dead Weight (kg)
12530
Gross Vehicle Weight (kg)
33000
Gross Combination Weight (kg)
80000
Overall Dimension(L*W*H)(mm)
8645×2560×3450
Wheelbase(mm)
3625+1350
Front/Rear Overhang( mm)
1500/725
Wheel Track(Front/Rear)(mm)
2022/1850
Min. Ground Clearance(mm)
314
Approach/Departure Angle( °)
16/70
Max. Speed (km/h)
92
Max. Gradebility (%)
≥40
The carriage Size
5800*2300*1500mm



Togo Sinotruck HOWO 6x4 Mining Dump Truck 20 Cubic Meter 10 Wheel 420hp Tipper Truck 0

Togo Sinotruck HOWO 6x4 Mining Dump Truck 20 Cubic Meter 10 Wheel 420hp Tipper Truck 1

Togo Sinotruck HOWO 6x4 Mining Dump Truck 20 Cubic Meter 10 Wheel 420hp Tipper Truck 2





Togo Sinotruck HOWO 6x4 Mining Dump Truck 20 Cubic Meter 10 Wheel 420hp Tipper Truck 3



Togo Sinotruck HOWO 6x4 Mining Dump Truck 20 Cubic Meter 10 Wheel 420hp Tipper Truck 4
