Howo New 6X4 10 Tire Diesel Manual Heavy Tipper Dump Truck With Weichai Engine Euro 2 Emission Standard Left Steering

Howo New 6X4 10 Tire Diesel Manual Heavy Tipper Dump Truck With Weichai Engine Euro 2 Emission Standard Left Steering
Howo New 6X4 10 Tire Diesel Manual Heavy Tipper Dump Truck With Weichai Engine Euro 2 Emission Standard Left Steering Howo New 6X4 10 Tire Diesel Manual Heavy Tipper Dump Truck With Weichai Engine Euro 2 Emission Standard Left Steering Howo New 6X4 10 Tire Diesel Manual Heavy Tipper Dump Truck With Weichai Engine Euro 2 Emission Standard Left Steering Howo New 6X4 10 Tire Diesel Manual Heavy Tipper Dump Truck With Weichai Engine Euro 2 Emission Standard Left Steering Howo New 6X4 10 Tire Diesel Manual Heavy Tipper Dump Truck With Weichai Engine Euro 2 Emission Standard Left Steering Howo New 6X4 10 Tire Diesel Manual Heavy Tipper Dump Truck With Weichai Engine Euro 2 Emission Standard Left Steering

Large Image :  Howo New 6X4 10 Tire Diesel Manual Heavy Tipper Dump Truck With Weichai Engine Euro 2 Emission Standard Left Steering

Product Details:
Place of Origin: China
Brand Name: Howo
Certification: ISO CCC
Model Number: jnhtc
Payment & Shipping Terms:
Minimum Order Quantity: 1 UNIT
Price: USD23100-25410
Packaging Details: nude
Delivery Time: 45 Work days
Payment Terms: L/C, T/T
Supply Ability: 50 units per week

Howo New 6X4 10 Tire Diesel Manual Heavy Tipper Dump Truck With Weichai Engine Euro 2 Emission Standard Left Steering

Description
Horsepower: 400hp Fuel Tank: 400L
Drive Wheel: 8x4 Engine Capacity: > 8L
Capacity (Load): 21 - 30T Brand Name: SINOTRUK
Segement: Heavy Truck
Highlight:

Left Steering Heavy Tipper Dump Truck

,

10 Tire Heavy Tipper Dump Truck

,

Weichai Engine howo 6x4 dump truck

Howo New 6X4 10 Tire Diesel Manual Heavy Tipper Dump Truck With Weichai Engine Euro 2 Emission Standard Left Steering



Model
ZZ3257V3847B1
Driver's Cab
HW76 extended cab, with one sleeper berth ,with air conditioner, air seat for driver. MP3
Engine
Model: WP12.400E201, Euro II emission standard, 4 stroke injection diesel engine, 6
cylinder in-line with water cooling, turbo-charging & inter cooling.
Maximum output: 400PS (294kW) at 2100 rpm
Maximum torque: 2060Nm at 1200-1500rpm
Bore: 126mm Stroke: 155mm
Displacement: 11.596L
Brand: Weichai
Steering
Model: BOSCH
Hydraulic steering with power assistance
Left hand driving
Clutch
Φ430 Pull-type diaphragm spring clutch
Transmission
Model: HW19710, 10 forward and 2 reverse
Manual type
With transmission power take-off HW70
Max Torque: 1900N·M
Front Axle
Model: HF9
Drum brake system
Rated loading capacity :9000kgs
Rear Axle
Model: MCP16ZG
Capacity: 16000kgs
Drum braking steering axle,self-adjusting arm
Speed ratio:
Wheelbase
3800+1350 mm
Brake System
Type :Wabco braking system
ABS 4S/4M
Engine exhaust valve brake
Oil Tanker
300L aluminum alloy fuel tank
Tires
Types: 12.00R20 radial tire; 18PR
10 pcs, plus one pc spare tire
Bumper
Metal bumper
Dump body
5600*2300*1500mm, 8mm for bottom and 6 mm for side plate, rectangular box, Chinese brand front lifting cylinder, with integral
fender, headlight cover.
Dimensions in mm
Front wheel track (mm): 2022
Rear wheel track (mm):1830
Overhang(front/rear) (mm):1500/1870
Overall Dimension (mm): 8650*2580*3450
Weight in kg
Dead weight (kg):13500
Gross vehicle weight (kg):25000


A dump truck, also known as a dumper truck or tipper truck, is used for transporting loose material, such as sand, gravel, or demolition waste, for construction. Here are some key details:

Types of Dump Trucks

  1. Standard Dump Truck

    • Has a truck chassis with a dump body mounted to the frame.
    • Equipped with a hydraulic ram to lift the front of the body, allowing material to be dumped out the back.
  2. Articulated Dump Truck (ADT)

    • Has a hinge between the cab and the dump box.
    • Offers excellent maneuverability and is suited for rough terrain.
  3. Transfer Dump Truck

    • Standard dump truck pulling a separate trailer with a movable cargo container.
    • Allows for a higher payload capacity.
  4. Side Dump Truck

    • Features a hydraulic system that tilts the dump body to the side to unload.
    • Stable and can unload quickly.
  5. Superdump Truck

    • Standard dump truck with a trailing axle to increase load capacity.
    • Can carry heavier loads and still comply with road regulations.

Key Features

  • Hydraulic System: Essential for lifting the dump body.
  • Durable Construction: Able to handle heavy and abrasive materials.
  • High Payload Capacity: Varies depending on the type and size of the truck.
  • Off-road Capabilities: Especially in articulated and superdump trucks.

Uses

  • Construction: Transporting materials like sand, gravel, and concrete.
  • Mining: Moving ore, coal, and other mined materials.
  • Landscaping: Hauling soil, mulch, and other landscaping materials.
  • Municipal: Snow removal, waste management, and other public works.

Considerations When Choosing a Dump Truck

  1. Payload Capacity: Ensure the truck can handle the weight of the materials you need to transport.
  2. Terrain: Choose a model suited for the environment in which it will operate.
  3. Maintenance: Consider the ease of maintaining the hydraulic systems and other components.
  4. Regulations: Ensure the truck complies with local road and safety regulations.



Howo New 6X4 10 Tire Diesel Manual Heavy Tipper Dump Truck With Weichai Engine Euro 2 Emission Standard Left Steering 0Howo New 6X4 10 Tire Diesel Manual Heavy Tipper Dump Truck With Weichai Engine Euro 2 Emission Standard Left Steering 1Howo New 6X4 10 Tire Diesel Manual Heavy Tipper Dump Truck With Weichai Engine Euro 2 Emission Standard Left Steering 2Howo New 6X4 10 Tire Diesel Manual Heavy Tipper Dump Truck With Weichai Engine Euro 2 Emission Standard Left Steering 3Howo New 6X4 10 Tire Diesel Manual Heavy Tipper Dump Truck With Weichai Engine Euro 2 Emission Standard Left Steering 4





Howo New 6X4 10 Tire Diesel Manual Heavy Tipper Dump Truck With Weichai Engine Euro 2 Emission Standard Left Steering 5Howo New 6X4 10 Tire Diesel Manual Heavy Tipper Dump Truck With Weichai Engine Euro 2 Emission Standard Left Steering 6Howo New 6X4 10 Tire Diesel Manual Heavy Tipper Dump Truck With Weichai Engine Euro 2 Emission Standard Left Steering 7Howo New 6X4 10 Tire Diesel Manual Heavy Tipper Dump Truck With Weichai Engine Euro 2 Emission Standard Left Steering 8Howo New 6X4 10 Tire Diesel Manual Heavy Tipper Dump Truck With Weichai Engine Euro 2 Emission Standard Left Steering 9
