Hot Selling HOWO 6X4 380HP 20 Cubic Meters Tipper Truck Used Dump Trucks With Cheap Price

Hot Selling HOWO 6X4 380HP 20 Cubic Meters Tipper Truck Used Dump Trucks With Cheap Price
Hot Selling HOWO 6X4 380HP 20 Cubic Meters Tipper Truck Used Dump Trucks With Cheap Price Hot Selling HOWO 6X4 380HP 20 Cubic Meters Tipper Truck Used Dump Trucks With Cheap Price Hot Selling HOWO 6X4 380HP 20 Cubic Meters Tipper Truck Used Dump Trucks With Cheap Price Hot Selling HOWO 6X4 380HP 20 Cubic Meters Tipper Truck Used Dump Trucks With Cheap Price Hot Selling HOWO 6X4 380HP 20 Cubic Meters Tipper Truck Used Dump Trucks With Cheap Price Hot Selling HOWO 6X4 380HP 20 Cubic Meters Tipper Truck Used Dump Trucks With Cheap Price

Large Image :  Hot Selling HOWO 6X4 380HP 20 Cubic Meters Tipper Truck Used Dump Trucks With Cheap Price

Product Details:
Place of Origin: China
Brand Name: Howo
Certification: ISO CCC
Model Number: jnhtc
Payment & Shipping Terms:
Minimum Order Quantity: 1 UNIT
Price: USD23100-25410
Packaging Details: nude
Delivery Time: 45 Work days
Payment Terms: L/C, T/T
Supply Ability: 50 units per week

Hot Selling HOWO 6X4 380HP 20 Cubic Meters Tipper Truck Used Dump Trucks With Cheap Price

Description
Horsepower: 380hp Fuel Tank: 400L
Drive Wheel: 6x4 Tyres: 12.00R20
Capacity (Load): 21 - 30T Steering: Left
Cargo Tank Length: 5.3-6.2M
Highlight:

380HP Tipper Truck

,

Used Dump Trucks Tipper Truck

,

20 Cubic Meters Tipper Truck

Hot Selling HOWO 6X4 380HP 20 Cubic Meters Tipper Truck Used Dump Trucks With Cheap Price



Model
ZZ3257V3847B1
Driver's Cab
HW76 extended cab, with one sleeper berth ,with air conditioner, air seat for driver. MP3
Engine
Model: WP12.400E201, Euro II emission standard, 4 stroke injection diesel engine, 6
cylinder in-line with water cooling, turbo-charging & inter cooling.
Maximum output: 400PS (294kW) at 2100 rpm
Maximum torque: 2060Nm at 1200-1500rpm
Bore: 126mm Stroke: 155mm
Displacement: 11.596L
Brand: Weichai
Steering
Model: BOSCH
Hydraulic steering with power assistance
Left hand driving
Clutch
Φ430 Pull-type diaphragm spring clutch
Transmission
Model: HW19710, 10 forward and 2 reverse
Manual type
With transmission power take-off HW70
Max Torque: 1900N·M
Front Axle
Model: HF9
Drum brake system
Rated loading capacity :9000kgs
Rear Axle
Model: MCP16ZG
Capacity: 16000kgs
Drum braking steering axle,self-adjusting arm
Speed ratio:
Wheelbase
3800+1350 mm
Brake System
Type :Wabco braking system
ABS 4S/4M
Engine exhaust valve brake
Oil Tanker
300L aluminum alloy fuel tank
Tires
Types: 12.00R20 radial tire; 18PR
10 pcs, plus one pc spare tire
Bumper
Metal bumper
Dump body
5600*2300*1500mm, 8mm for bottom and 6 mm for side plate, rectangular box, Chinese brand front lifting cylinder, with integral
fender, headlight cover.
Dimensions in mm
Front wheel track (mm): 2022
Rear wheel track (mm):1830
Overhang(front/rear) (mm):1500/1870
Overall Dimension (mm): 8650*2580*3450
Weight in kg
Dead weight (kg):13500
Gross vehicle weight (kg):25000


A dump truck is a versatile and robust vehicle designed primarily for transporting loose materials such as

sand, gravel, dirt, or debris in various industries. Here are some additional details about dump trucks:

  1. Design and Structure: Dump trucks typically consist of a cab where the driver sits, a chassis that

  2. supports the truck's structure and components, and a dump body or bed at the rear. The dump

  3. body is usually hydraulically operated, allowing it to tilt and dump its contents.

  4. Types of Dump Trucks:

    • Standard Dump Trucks: These have a rigid chassis and are commonly used for transporting
    • materials on highways and paved surfaces.
    • Articulated Dump Trucks: These have a hinge between the cab and the dump box, which
    • provides better maneuverability on rough terrain, making them ideal for mining and off-road
    • applications.
    • Side Dump Trucks: These unload by tilting to the side, which can be useful for dumping
    • alongside trenches or walls.
  5. Capacity: Dump trucks come in various sizes, ranging from small trucks used for residential

  6. landscaping to large, heavy-duty trucks capable of carrying several tons of material. The capacity

  7. depends on factors such as the size of the dump bed and the truck's overall design.

  8. Power and Performance: Dump trucks are typically powered by diesel engines for their torque and

  9. fuel efficiency, especially in heavy-duty applications. They are designed with robust suspension

  10. systems to handle the weight of heavy loads and uneven terrain.

  11. Safety Features: Modern dump trucks are equipped with safety features such as stability control,

  12. anti-lock brakes, and backup cameras to ensure safe operation and minimize accidents during

  13. loading, transportation, and unloading.

  14. Applications: Dump trucks are essential in construction, mining, landscaping, and agriculture, where

  15. they are used to transport materials for building roads, foundations, and infrastructure, as well as for

  16. hauling earth and aggregate in excavation and mining operations.

Dump trucks are valued for their efficiency, versatility, and durability, making them indispensable in industries

that require reliable transportation of bulk materials over varying terrains and conditions.
