New HOWO TX Tipper Truck 6x4 Driving 380Hp 10 Wheeler Diesel Dump Truck For Sale

Certification
China Jinan Heavy Truck Import & Export Co., Ltd. certification
China Jinan Heavy Truck Import & Export Co., Ltd. certification
Customer Reviews
It feels good, very similar to MAN!

—— Hafiz Ahmed

Work with your company to save money, time and Energy .

—— Zahid Mohammed

Thank you for your continued support and service in past 6years .

—— Dave Balah

The best of quality with reasonable price and professional service give us deep confidence to build long term cooperation .

—— Jayson Kan

Good after sales service and quality

—— Mahanmd Steve

I'm Online Chat Now

New HOWO TX Tipper Truck 6x4 Driving 380Hp 10 Wheeler Diesel Dump Truck For Sale

New HOWO TX Tipper Truck 6x4 Driving 380Hp 10 Wheeler Diesel Dump Truck For Sale
New HOWO TX Tipper Truck 6x4 Driving 380Hp 10 Wheeler Diesel Dump Truck For Sale New HOWO TX Tipper Truck 6x4 Driving 380Hp 10 Wheeler Diesel Dump Truck For Sale New HOWO TX Tipper Truck 6x4 Driving 380Hp 10 Wheeler Diesel Dump Truck For Sale New HOWO TX Tipper Truck 6x4 Driving 380Hp 10 Wheeler Diesel Dump Truck For Sale New HOWO TX Tipper Truck 6x4 Driving 380Hp 10 Wheeler Diesel Dump Truck For Sale New HOWO TX Tipper Truck 6x4 Driving 380Hp 10 Wheeler Diesel Dump Truck For Sale

Large Image :  New HOWO TX Tipper Truck 6x4 Driving 380Hp 10 Wheeler Diesel Dump Truck For Sale

Product Details:
Place of Origin: China
Brand Name: Howo
Certification: ISO CCC
Model Number: jnhtc
Payment & Shipping Terms:
Minimum Order Quantity: 1 UNIT
Price: USD23100-25410
Packaging Details: nude
Delivery Time: 45 Work days
Payment Terms: L/C, T/T
Supply Ability: 50 units per week

New HOWO TX Tipper Truck 6x4 Driving 380Hp 10 Wheeler Diesel Dump Truck For Sale

Description
Horsepower: 340hp Delivery: Within 40 Worrkday
Fuel Tank: 400L Drive Wheel: 6X4 8X4
Tyres: 12.00R20 Capacity (Load): 25T
Color: Red White Yellow Orange Green
Highlight:

6x4 Driving Diesel Dump Truck

,

380Hp Diesel Dump Truck

,

10 Wheeler Diesel Dump Truck

New HOWO TX Tipper Truck 6x4 Driving 380Hp 10 Wheeler Diesel Dump Truck For Sale



Model
ZZ3257V3847B1
Driver's Cab
HW76 extended cab, with one sleeper berth ,with air conditioner, air seat for driver. MP3
Engine
Model: WP12.400E201, Euro II emission standard, 4 stroke injection diesel engine, 6
cylinder in-line with water cooling, turbo-charging & inter cooling.
Maximum output: 400PS (294kW) at 2100 rpm
Maximum torque: 2060Nm at 1200-1500rpm
Bore: 126mm Stroke: 155mm
Displacement: 11.596L
Brand: Weichai
Steering
Model: BOSCH
Hydraulic steering with power assistance
Left hand driving
Clutch
Φ430 Pull-type diaphragm spring clutch
Transmission
Model: HW19710, 10 forward and 2 reverse
Manual type
With transmission power take-off HW70
Max Torque: 1900N·M
Front Axle
Model: HF9
Drum brake system
Rated loading capacity :9000kgs
Rear Axle
Model: MCP16ZG
Capacity: 16000kgs
Drum braking steering axle,self-adjusting arm
Speed ratio:
Wheelbase
3800+1350 mm
Brake System
Type :Wabco braking system
ABS 4S/4M
Engine exhaust valve brake
Oil Tanker
300L aluminum alloy fuel tank
Tires
Types: 12.00R20 radial tire; 18PR
10 pcs, plus one pc spare tire
Bumper
Metal bumper
Dump body
5600*2300*1500mm, 8mm for bottom and 6 mm for side plate, rectangular box, Chinese brand front lifting cylinder, with integral
fender, headlight cover.
Dimensions in mm
Front wheel track (mm): 2022
Rear wheel track (mm):1830
Overhang(front/rear) (mm):1500/1870
Overall Dimension (mm): 8650*2580*3450
Weight in kg
Dead weight (kg):13500
Gross vehicle weight (kg):25000



New HOWO TX Tipper Truck 6x4 Driving 380Hp 10 Wheeler Diesel Dump Truck For Sale 0New HOWO TX Tipper Truck 6x4 Driving 380Hp 10 Wheeler Diesel Dump Truck For Sale 1New HOWO TX Tipper Truck 6x4 Driving 380Hp 10 Wheeler Diesel Dump Truck For Sale 2New HOWO TX Tipper Truck 6x4 Driving 380Hp 10 Wheeler Diesel Dump Truck For Sale 3New HOWO TX Tipper Truck 6x4 Driving 380Hp 10 Wheeler Diesel Dump Truck For Sale 4

A dump truck, also known as a dump truck, is a heavy-duty truck used for transporting and

dumping bulk materials, widely used in industries such as construction, mining, agriculture,

and waste management. Its main feature is the tiltable cargo box, which can be lifted by a

hydraulic system to easily dump materials in designated positions, greatly improving loading

and unloading efficiency.
Classification of dump trucks
Standard dump truck: This is the most common type of dump truck, typically equipped with a

separate compartment that can be tilted at the rear to dump materials.
Side dumping dump truck: The cargo box of this dump truck can tilt to the side, used for unloading

in narrow spaces or specific scenarios.
Bidirectional tilting dump truck: It has multiple tilting directions, making it easy to operate on

complex sites.
Mining dump truck: suitable for mining and heavy mining environments, with high load-bearing

capacity and sturdy chassis, usually capable of carrying tens to hundreds of tons of materials.
Key features of dump truck
Loading and transportation: It has a large load-bearing capacity and can easily transport heavy

objects such as stones, soil, and gravel.
Convenient dumping: The hydraulic system can quickly lift the cargo box, unload materials quickly,

and reduce manual operation.
Off road performance: Many dump trucks are designed with powerful off-road capabilities, suitable

for driving on complex road conditions such as mud, sand, gravel, etc.



New HOWO TX Tipper Truck 6x4 Driving 380Hp 10 Wheeler Diesel Dump Truck For Sale 5New HOWO TX Tipper Truck 6x4 Driving 380Hp 10 Wheeler Diesel Dump Truck For Sale 6New HOWO TX Tipper Truck 6x4 Driving 380Hp 10 Wheeler Diesel Dump Truck For Sale 7New HOWO TX Tipper Truck 6x4 Driving 380Hp 10 Wheeler Diesel Dump Truck For Sale 8New HOWO TX Tipper Truck 6x4 Driving 380Hp 10 Wheeler Diesel Dump Truck For Sale 9
