Product Details:
|
| Engine: | WD615.469 | Driving Type: | 6*4 Left |
|---|---|---|---|
| Color: | White Red Blue(optional) | Capacity: | 20cbm |
| Fuel Tank Material: | Aluminium Alloy | ||
| Highlight: | 340hp Tipper Truck Chassis,6x4 Tipper Truck Chassis,10 Wheels Tipper Truck Chassis |
||
|
Howo 6*4 Dump Truck Chassis
|
|||||||
|
Cabin
|
HW70(NO BED);HW76(SINGLE BED)
|
||||||
|
engine
|
Model
|
Wd615.62
|
Wd615.87
|
Wd615.69
|
|||
|
Fuel
|
Diesel
|
||||||
|
Displacement
|
9.726L
|
||||||
|
Emission Standard
|
EURII
|
||||||
|
Power
|
196(266)/2200
|
213(290)/2200
|
247(336)/2200
|
||||
|
torque
|
1100/1100-1600
|
1160/1160-1600
|
1350/1100-1600
|
||||
|
transmission
|
model
|
HW19710
|
|||||
|
Control model
|
MT
|
||||||
|
Front axle
|
HF9 drum-type rated load of 9tons
|
||||||
|
Rear axle
|
St16 16tons speed ratio:3.93 4.42 4.8
|
||||||
|
Clutch
|
Single-plate dry diaphragm spring clutch, diameter 430(B)mm, hydraulically operating with air assistance
|
||||||
|
steering
|
ZF8098
|
||||||
|
Suspension
|
Leaf spring suspension
|
||||||
|
Fuel tank
|
300L
|
||||||
|
tyres
|
12.00R20
|
||||||
