HOHAN Tipper Truck 8x8 Driving 12 Wheeler Diesel Dump Truck For Sale

HOHAN Tipper Truck 8x8 Driving 12 Wheeler Diesel Dump Truck For Sale
HOHAN Tipper Truck 8x8 Driving 12 Wheeler Diesel Dump Truck For Sale HOHAN Tipper Truck 8x8 Driving 12 Wheeler Diesel Dump Truck For Sale HOHAN Tipper Truck 8x8 Driving 12 Wheeler Diesel Dump Truck For Sale HOHAN Tipper Truck 8x8 Driving 12 Wheeler Diesel Dump Truck For Sale HOHAN Tipper Truck 8x8 Driving 12 Wheeler Diesel Dump Truck For Sale HOHAN Tipper Truck 8x8 Driving 12 Wheeler Diesel Dump Truck For Sale

Large Image :  HOHAN Tipper Truck 8x8 Driving 12 Wheeler Diesel Dump Truck For Sale

Product Details:
Place of Origin: China
Brand Name: Howo
Certification: ISO CCC
Model Number: jnhtc
Payment & Shipping Terms:
Minimum Order Quantity: 1 UNIT
Price: USD23100-25410
Packaging Details: nude
Delivery Time: 45 Work days
Payment Terms: L/C, T/T
Supply Ability: 50 units per week

HOHAN Tipper Truck 8x8 Driving 12 Wheeler Diesel Dump Truck For Sale

Description
Horsepower: 340hp Condition: New
Fuel Tank: 400L Drive Wheel: 6X4 8X8
Tyres: 12.00R20 Capacity (Load): 25T
Color: White And Others Cargo Tank Dimension: 5600*2300*1500
Highlight:

8x8 Driving Diesel Dump Truck

,

12 Wheeler Diesel Dump Truck

,

HOHAN Diesel Dump Truck

HOHAN Tipper Truck 8x8 Driving 12 Wheeler Diesel Dump Truck For Sale



Model
ZZ3257V3847B1
Driver's Cab
HW76 extended cab, with one sleeper berth ,with air conditioner, air seat for driver. MP3
Engine
Model: WP12.400E201, Euro II emission standard, 4 stroke injection diesel engine, 6
cylinder in-line with water cooling, turbo-charging & inter cooling.
Maximum output: 400PS (294kW) at 2100 rpm
Maximum torque: 2060Nm at 1200-1500rpm
Bore: 126mm Stroke: 155mm
Displacement: 11.596L
Brand: Weichai
Steering
Model: BOSCH
Hydraulic steering with power assistance
Left hand driving
Clutch
Φ430 Pull-type diaphragm spring clutch
Transmission
Model: HW19710, 10 forward and 2 reverse
Manual type
With transmission power take-off HW70
Max Torque: 1900N·M
Front Axle
Model: HF9
Drum brake system
Rated loading capacity :9000kgs
Rear Axle
Model: MCP16ZG
Capacity: 16000kgs
Drum braking steering axle,self-adjusting arm
Speed ratio:
Wheelbase
3800+1350 mm
Brake System
Type :Wabco braking system
ABS 4S/4M
Engine exhaust valve brake
Oil Tanker
300L aluminum alloy fuel tank
Tires
Types: 12.00R20 radial tire; 18PR
10 pcs, plus one pc spare tire
Bumper
Metal bumper
Dump body
5600*2300*1500mm, 8mm for bottom and 6 mm for side plate, rectangular box, Chinese brand front lifting cylinder, with integral
fender, headlight cover.
Dimensions in mm
Front wheel track (mm): 2022
Rear wheel track (mm):1830
Overhang(front/rear) (mm):1500/1870
Overall Dimension (mm): 8650*2580*3450
Weight in kg
Dead weight (kg):13500
Gross vehicle weight (kg):25000

A Dump Truck is a heavy-duty vehicle designed primarily for transporting and unloading loose materials, such as sand, gravel, demolition waste, and construction debris. These trucks are widely used in construction, mining, road work, and similar industries where bulk material handling is required.

Here are the key characteristics and types of dump trucks:

  1. Basic Structure: A dump truck consists of a large open-box bed attached to the truck's chassis. The bed is typically made of reinforced steel to handle heavy loads and abrasive materials. The back of the bed is hinged, allowing it to tilt and dump its contents.

  2. Hydraulic Lift System: The dump bed is raised by a hydraulic lift system, allowing materials to slide out of the back. This hydraulic mechanism is essential for quick unloading, as it tilts the bed upwards, guiding the material toward the rear exit.

  3. Types of Dump Trucks:

    • Standard Dump Truck: Features a single front axle and one or more rear axles, with the dump bed attached to a frame. The bed raises with a hydraulic arm, tilting to unload from the back.
    • Articulated Dump Truck (ADT): Has a pivot joint between the cab and the dump bed, offering greater flexibility and maneuverability, especially on rough terrains. These are common in mining and large-scale construction.
    • Side Dump Truck: Equipped with a hydraulic system that allows the bed to tilt sideways, which can be safer and quicker for unloading materials in some situations.
    • Transfer Dump Truck: Uses an additional trailer (referred to as a "B box") to carry extra loads. The trailer is pulled by the main dump truck and can be detached for unloading in multiple areas.
    • Super Dump Truck: A specialized truck that includes additional trailing axles, allowing it to carry very heavy loads while complying with weight regulations.
