Shacman X5000 6x4 10 Wheeler Tipper Dump Truck for Construction Transportation

Large Image : Shacman X5000 6x4 10 Wheeler Tipper Dump Truck for Construction Transportation

Product Details:

Place of Origin:	Xi'An
Brand Name:	SHACMAN
Certification:	ISO,CCC,GCC
Model Number:	SX3255DT384

Payment & Shipping Terms:

Minimum Order Quantity:	1 Unit
Price:	FOB 30000-33000 USD Per Unit
Packaging Details:	Nude,wax before shipping.
Delivery Time:	30 Working Days
Payment Terms:	L/C, T/T
Supply Ability:	300 Units Per Month

Contact Now

Shacman X5000 6x4 10 Wheeler Tipper Dump Truck for Construction Transportation

Description

Steering:	Left/right	Place Of Origin:	Shandong Jinan
Engine Brand:	WEICHAI	Capacity (load):	35t
Horsepower:	520hp	Emission Standard:	Euro 2-Euro 6
Highlight:	Shacman X5000 6x4 dump truck , 10 wheeler tipper truck , heavy duty construction dump truck

Shacman X5000 6x4 10 Wheeler Tipper Dump Truck for Construction Transportation

Drive type		6×4
Complete kerb mass (kg)		11200
Max.total mass (kg)		25000
Max.speed (km/h)		70
Min.turning circle(m)		18
Min.ground clearance(mm)		314
Approach / Departure angle (°)		16/66
Max.gradeability(%)		40
Appearance dimensions (mm)	Max.length	8275
	Max.width	2490
	Max.heigh	3300
Front / Rear overhang		1525/1600
Wheel base(mm)		3800+1350
Track width(mm)		1939 / 1800
Engine		WP10.290
Rated Output (kw/ps)		228/290
Clutch		φ420mmSpring-loaded clutch damper
Transmission		FULLER 9JS135
Gear ratio		12.11 8.08 5.93 4.42 3.36 2.41 1.76 1.32 1.00 12.66R
Front axle		7.5tons
Rear axle		Shan Qi Steyr military reinforced axle 13tons
Steering		Integral inner circulation power sreering
Cab		D'LONG F2000, flat roof
Tire		12.00R20
Fuel consumption for 100km(50km/h) L		36
Fuel tank capacity (L)		300
Platform dimensions(mm)		560023001500 middle lift

Shacman X5000 6x4 10 Wheeler Tipper Dump Truck for Construction Transportation 0

Shacman X5000 6x4 10 Wheeler Tipper Dump Truck for Construction Transportation 5

Shacman X5000 6x4 10 Wheeler Tipper Dump Truck for Construction Transportation 6
